| Tractor PTO Speed (rpm) |
540 |
| Tractor PTO HP |
25-60 |
| Shipping Weight (lbs) |
2051 |
| Hitch |
CAT 2 Drawbar |
| Cutting Width (in) |
144 |
| Cutting Height (in) |
1.5 – 4.5 |
| Wing Deck Cut Width (in) |
48 |
| Center Deck Cut Width (in) |
60 |
| Deck Overlap (in) |
6 |
| Overall Width (in) |
147 |
| Max Overall Length (in) |
141 |
| Transport Width (in) |
91 |
| Transport Length (in) |
135 |
| Splitter Gearbox HP |
100 |
| Blade Tip Speed (fpm) |
18,000 |
| Drive Type |
Gearbox over v-belt |
| Input Driveline |
CAT 3 (CV) |
| Wing Drivelines |
CAT 3 |
| Transport Tires (in) |
(2) 20.5 x 8-10 |
| Caster Wheels (in) |
(10) 8 x 3.5 solid |
| Wing Deck Lift Cylinders |
3 x 10 single-acting |
| Center Deck Lift Cylinders |
3 x 8 single-acting |
| Trailer Frame Construction |
4.0 x 4.0 x .25 square tube |
| Deck Thickness |
10 gauge |
| Blade Spindles |
(9) ductile iron, lubed-for-life |
| Blade Dimensions (in) |
(6) .25 x 2.5 x 17.0, (3) .25 x 2.5 x 20.8 |
| Hitch Adjustment |
Floating clevis, multi-position |
| Transport Lock |
Automatic, manual release |
| Transport Tires |
Non-highway speed-rated |
| Cut Height Adjustment |
Caster spacers |
| Belt Construction |
B-section, Kevlar® |
| Belt Cover |
Clutching cover |
| Belt Adjustment |
Spring-loaded idler |
| Rear Chain Shielding |
Optional |
| Anti-Scalp Rollers |
(1) Front and (2) Rear Optional |
| Light Kit |
Optional |
| Hydraulic Wing Unlock |
Optional |
| Gearbox Warranty |
3 year homeowners, 1 year commercial |
| Mower Warranty |
1 year |
| Spindle Warranty |
1 year |
