Manitou MSI 35 3B / FT4

Call Now Get A Quote Schedule A Visit Value Your Trade Apply for Financing

Description

The MSI 35 is a one-of-a-kind forklift truck perfect for handling longer or heavier loads up to 3.5 tonnes. It comes equipped with two-wheel drive and can be fitted with a wide range of tires and attachments for incredible versatility. The hydrostatic transmission enhances precision and positioning when approaching loads for improved performance.The suspended driver’s cab absorbs vibrations during operations, for maximum comfort over the course of a shift. A spacious working area includes ergonomic commands, and access is made easy with a large footstep and handle grip.

Condition

New

Lifting height	10'10"
Lifting capacity	7700 lb
Drawbar pull	5935 lbf
Moving speed	12.4 mph
Mast inclination (front/rear)	10°
Length (up to the back of the fork)	9'11"
Total length (fork included)	13'7"
Wheelbase length	5'11"
Width	4'4"
Fork carriage width	4'2"
Aisle width (with a 1000 x 1200 palette)	15.06
Aisle width (with a 800 x 1200 palette)	15.38
Height	7'6"
Weight (unladen)	10659 lb
Front axle weight (laden)	16380 lb
Front axle weight (unladen)	3814 lb
Rear axle weight (laden)	2017 lb
Rear axle weight (unladen)	6867 lb
Turning radius	8'8"
Ground clearance	0'10"
Energy	Diesel
Engine brand	Kubota
Engine type	3B / Tier IV Final
Engine manufacturer type	V2403 CR TE4
Power	48.6 KW
Number of cylinders	4
Total capacity	148.5 in3
Transmission type	Hydrostatic
Pressure	190 bars
Standard tyres	Pneumatic
Number of wheels (front/rear)	2/2
Number of drive wheels (front/rear)	2/0
Number of steering wheels (front/rear)	0/2
Standard mast type	Duplex
Free lift (standard mast, lowered)	0'5"
Standard mast height (when raised)	13'9"
