Manitou M 30-2

Call Now Get A Quote Schedule A Visit Value Your Trade Apply for Financing

Description

The M 30-2 masted forklift truck is designed for sectors where activities involve extreme conditions (construction, the timber industry, mines, etc.). A truly all-terrain forklift truck, it comes equipped with 37 cm of ground clearance, allowing for excellent manoeuvrability, with optimised dimensions for improved stability.The large number of masts available for this unit have all been designed for use in demanding environments or with longer loads–the result of Manitou’s expertise put into practice, they are suitably robust and easy to use. And with a 75 hp engine, the M 30-2 is powerful enough to ensure optimal work efficiency.

Condition New
Lifting height 12'2"
Lifting capacity 6600 lb
Drawbar pull 10498 lbf
Moving speed 6.2 mph
Mast inclination (front/rear) 6°
Length (up to the back of the fork) 11'7"
Total length (fork included) 15'6"
Wheelbase length 6'8"
Width 6'5"
Fork carriage width 4'1"
Aisle width (with a 1000 x 1200 palette) 17.7
Aisle width (with a 800 x 1200 palette) 17.7
Height 9'0"
Weight (unladen) 13117 lb
Front axle weight (laden) 16567 lb
Front axle weight (unladen) 5213 lb
Rear axle weight (laden) 3163 lb
Rear axle weight (unladen) 7903 lb
Turning radius 10'8"
Ground clearance 1'6"
Energy Diesel
Engine brand Perkins
Engine type Stage 3B
Engine manufacturer type 854F-E34T 54009.1
Power 55 KW
Max. Torque @ Rotation 318 Nm
Number of cylinders 4
Total capacity 207.4 in3
Injection Direct
Cooling Water
Transmission type Torque converter
Pressure 245 bars
Hydraulic oil tank volume 21 gal
Standard tyres Pneumatic
Number of wheels (front/rear) 2/2
Number of drive wheels (front/rear) 2/0
Number of steering wheels (front/rear) 0/2
Standard mast type Duplex
Free lift (standard mast, lowered) 0'5"
Standard mast height (when raised) 15'10"
Driving position noise levels 76 dB
Environmental noise levels 104 dB
Vibrations affecting hands/arms 2.5 m/s

Features

The M 30-2 masted forklift truck is designed for sectors where activities involve extreme conditions (construction, the timber industry, mines, etc.). A truly all-terrain forklift truck, it comes equipped with 37 cm of ground clearance, allowing for excellent manoeuvrability, with optimised dimensions for improved stability.

The large number of masts available for this unit have all been designed for use in demanding environments or with longer loads–the result of Manitou’s expertise put into practice, they are suitably robust and easy to use. And with a 75 hp engine, the M 30-2 is powerful enough to ensure optimal work efficiency.
