Engine Gross Power:Â 50.3 hp (37.5 kW)
PTO Type:Â Independent
Transmission Type:Â Hydrostatic
Shuttle:Â None
| Condition | New |
| Model | DK5310CHSE |
| Engine Model | 3H-TH4C |
| Engine Gross Power | 50.3 hp (37.5 kW) |
| Rated Speed | 2,600 rpm |
| No. of Cylinders | 3 |
| Fuel Type | Diesel |
| Displacement | 111.4 cu. in. (1,826 cc) |
| Fuel Tank Capacity | 12.7 gal. (48 L) |
| Transmission Type | Hydrostatic |
| No. of Travel Speeds - Forward / Reverse | 3 Range |
| Min. Travel Speed of Forward w/ Ag @ Engine rated speed | 0 mph (0 km/h) |
| Max. Travel Speed of Forward w/ Ag @ Engine rated speed | 18.5 mph (29.7 km/h) |
| PTO Type Transmission | Independent |
| PTO Power | 39.3 hp (29.3 kW) |
| Rear PTO Speed | 540 rpm |
| Mid PTO Speed | 2,000 rpm (Optional) |
| Brakes | Wet Disc Type |
| Clutch | None |
| Length w/ 3-point hitch | 125.5 in. (3,189 mm) |
| Width | 62.8 in. (1,596 mm) |
| Height from Top of Cab | 93 in. (2,363 mm) |
| Wheelbase | 71.3 in. (1,810 mm) |
| Ground Clearance | 14.5 in. (368 mm) |
| Front Tread Ag Tires - Min | 49.2 in. (1,252 mm) |
| Rear Tread Ag Tires - Min | 49.2 in. (1,251 mm) |
| Min. Turning Radius w/ Brake | 8.63 ft. (2.6 m) |
| Total Pump Flow | 16.49 gpm (62.4 L/min) |
| Weight w/ Ag Tires w/ Cab | 4,043.3 lbs. (1,834 kg) |
