Woods Equipment FZ27

Call Now Get A Quote Schedule A Visit Value Your Trade Apply for Financing

Description

  • MX V-baffle creates strong suction, lifting grass for a precision cut and keeping dust under the deck
  • Long wheelbase for more even weight distribution improves rider comfort and stability on all terrains
  • Standard full suspension, adjustable seat reduces operator fatigue so you can mow in comfort for hours
  • Front-mount deck for greater visibility and ease of cutting under low-growing foliage
  • PowerTilt™ feature for ease of cleaning and maintenance available on all decks
  • TrueFloat™ decks follow the contour of the ground for better cut
  • Discontinued
  • NOTE: All gearbox horsepower ratings listed in the following specifications are based on Woods’ field testing.
Condition New
Model FZ27
Cutting Width (in) 61
Blade Tip Speed (fpm) 17,800
Cutting Height (in) 1 to 5
Horsepower 27 gas
Air Filter System Heavy-duty canister style – dual element
Deck Design Fabricated 5 in deep deck with welded bumper, patented V-baffle system, TrueFloat™ deck suspension, 3-bearing greasable spindles
Deck Tilt/Height Adjust Patented PowerTilt™ option on MX deck with power height adjustment
Decks Available MX – 61 in
Drive System Twin hydrostatic pumps and separate wheel motors; spin-on automotive style oil filter – uses 20W50 weight oil
Drive Tires (in) 23 x 10.5-12 turf, or 23 x 10.5-12 Chevron
Engine Type Kohler V-twin OHV
Est. Weight w/61 in Deck (lbs) 1,704
Features Fully adjustable suspension seat, cup holder, storage compartment, hour meter, flexible ShrubSaver, discharge chute
Fuel Capacity (gal) 8.5
Lubrication Full pressure with spin-on filter
Options Mulching kits, blower-driven grass collection system, sunshade
Forward Speed (mph) 10
Warranty 2 years or 2,000 hours, whichever comes first

Features

  • 27 hp gas Kohler V-Twin, 4-Cycle, Air-cooled engine
  • Long wheelbase for more even weight distribution improves rider comfort and stability on all terrains
  • Standard full suspension, adjustable seat reduces operator fatigue so you can mow in comfort for hours
  • Front-mount deck for greater visibility and ease of cutting under low-growing foliage
  • MX V-BaffleTM creates strong suction, lifting grass for a precision cut and keeping dust under the deck
  • PowerTiltTM feature available on all decks
  • TrueFloatTM decks follow the contour of the ground for better cut
  • Standard roll-over protection system (ROPS) for added safety
  • Anti-scalp roller standard
