DS8.30 Pull Type

Woods Equipment DS8.30 Pull Type

Description

Smooth, sloped-top deck sheds water and debris to prevent rust and corrosion
Cuts light brush up to 1.5 inches in diameter
Six-year gearbox limited warranty
Variable wheel spacing
96-inch pull-type dual-spindle rotary cutter
NOTE: All gearbox horsepower ratings listed in the following specifications are based on Woods’ field testing.

Condition	New
Model	DS8.30

Tractor PTO HP	35-75
Tractor Hitch	Pivoting clevis
Cutting Height Range (in)	2 to 12
Cutting Capacity Diameter (in)	1.5
Cutting Width (in)	96
Blade Tip Speed (fpm)	15,200
Weight (lbs)	1,467
Deck Thickness (in)	.135 (10 ga)
Side Frame Depth (in)	10
Gearbox Warranty	6 years
Overall Width /Length (in)	100 x 142 (25 in tires)
Gearbox HP	100 center, 75 spindle *Gearbox horsepower ratings listed are based on field testing.
Blade Dimensions (in)	.5 x 4
Quick-hitch Compatible	Yes
Wheel Selection	Laminated, severe duty new ag, foam filled new ag, 15 in rims
Optional Dual Wheels – Pull-type	No

Tractor PTO HP

35-75

Tractor Hitch

Pivoting clevis

Cutting Height Range (in)

2 to 12

Cutting Capacity Diameter (in)

1.5

Cutting Width (in)

Blade Tip Speed (fpm)

15,200

Weight (lbs)

1,467

Deck Thickness (in)

.135 (10 ga)

Side Frame Depth (in)

Gearbox Warranty

6 years

Overall Width /Length (in)

100 x 142 (25 in tires)

Gearbox HP

100 center, 75 spindle *Gearbox horsepower ratings listed are based on field testing.

Blade Dimensions (in)

.5 x 4

Quick-hitch Compatible

Yes

Wheel Selection

Laminated, severe duty new ag, foam filled new ag, 15 in rims

Optional Dual Wheels – Pull-type
