H&S 5242

Call Now Get A Quote Schedule A Visit Value Your Trade Apply for Financing

Description

TOP SHOT SIDE DISCHARGE MANURE SPREADER MODEL 5242 – 4200 GALLON

ALL MODELS EXCEPT THE 5215 are available with the optional Digi-Star GT400, or Nutrient Tracker Scale System with GPS!

The heavy-duty expeller system with a quick release poly-lined fine spread pan, and side fins help cut the drift of material towards the tractor and spreader, and provide an excellent spread pattern.

FEATURES

40″ Wide “Top Shot” Expeller Beater

30″ Diameter Round Core Segmented Auger

Heavy Duty Gearbox Reduction

Overrunning Clutch /Torque Limiting Clutch

Left Side Poly Lined Tank

Front and Rear Splash Guards

Flip-Over Adjustable Hitch

Shear Bolt Protection

The auger System hydraulically raise and lower a full 8″ to break-up material that may bridge during the unloading process.

Automatic Chain Oiler System

Highway Lighting System

Remote Grease System

Hydraulic Lid (Optional)

OPTIONS

The 5234 & 5242 feature an optional hydraulic lid can be installed to open and latch from either side. A 3rd tractor remote is needed to operate the opening and closing of the lid. This remote is also used in conjunction with an electrical toggle switch to activate the switching of the hydraulic valve that operates the hydraulic cylinder to lock and unlock the lid.

Condition New
Model 5242
5242
CUBIC FT. STRUCK LEVEL 564
GALLON CAPACITY 4200
TANK LENGTH 20′
OVERALL LENGTH 27′ 7″
TANK WIDTH - TOP 97″
AUGER DIAMETER 30″
POLY LINED TANK Left Side
OVERRUNNING CLUTCH Yes
SHEAR BOLT PROTECTION Yes
PTO 1000 RPM 1 ¾″ Std. or 1000 RPM 1 ⅜″ Opt.
EXPELLER WIDTH 40″
FRONT SPLASHGUARDS Standard
REAR SPLASHGUARDS Standard
AUTOMATIC OILER Standard
HIGHWAY LIGHTING Standard
WEIGHT 16,500#
TIRE SPECIFICATIONS
w/28L X 26 Tires
SIDE LOADING HEIGHT 93″
HEIGHT @ REAR CYL. BRACKET N/A
HEIGHT @ FRONT SPLASH 101″
HEIGHT @ REAR SPLASH 101″
OVERALL WIDTH 125″
WARRANTY: SEE OPERATORS MANUAL FOR WARRANTY DETAILS AND LIMITATIONS. H&S RESERVES THE RIGHT TO CHANGE ITS PRODUCTS OR THE DESCRIPTION AT ANY TIME WITHOUT NOTICE OR OBLIGATION. MODELS AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE.
