McFarlane WDL-2100 Spike Tooth Harrow

Call Now Get A Quote Schedule A Visit Value Your Trade Apply for Financing

Description

The McFarlane WDL-2100 16-Bar Rear Fold Harrow is built for total tillage performance—doubling coverage and field efficiency with 16 flexible spike tooth bars across every pass. Designed for superior soil leveling, spring field preparation, and shallow chemical incorporation, this harrow thoroughly breaks, stirs, and mixes soil in one trip. With twice the normal number of bars and 20 high-carbon diamond-shaped teeth per foot, the WDL-2100 creates a planter-ready seedbed faster and more evenly than conventional harrows.

Durability comes standard with a one-piece main frame made from rectangular tubular steel, heavy-duty 7″x7″ toolbar, and maintenance-free bushings. A long hitch makes for easy turns, and dual wing wheels offer excellent flotation and transport stability. The auto backup bar enables tight maneuvering and quick transformation to transport position, making this harrow ideal for large-acre farms and custom operators.

Choose the McFarlane WDL-2100 16-Bar Harrow for shallow chemical incorporation, managing small grain straw, leveling chisel plow ridges, or broadcast seeding. Experience better seedbed preparation, more uniform herbicide incorporation, and true field efficiency—backed by Parallel Ag.

Condition New
Model WDL-2100 Spike Tooth Harrow

Compare Models

60'4" WDL-2160-16 | 16-Bar Sections / 20 Teeth per ft. / 15'2" Transport Width.
Model WDL-2160-16.
Cutting Width 60 ft. 4 in.
Weight 12,174 Lbs.
69'5" WDL-2170-16 | 16-Bar Sections / 20 Teeth per ft. / 15'2" Transport Width.
Model WDL-2170-16.
Cutting Width 69 ft. 5 in.
Weight 13,632 Lbs.
80'0" WDL-2180-16 | 16-Bar Sections / 20 Teeth per ft. / 15'2" Transport Width.
Model WDL-2180-16.
Cutting Width 80 ft. 0 in.
Weight 15,170 Lbs.
90'0" WDL-2190-16 | 16-Bar Sections / 20 Teeth per ft. / 15'2" Transport Width.
Model WDL-2190-16.
Cutting Width 90 ft. 0 in.
Weight 16,400 Lbs.

Features

Double Coverage, Double Performance

16-Bar Sections.
Twice the bars of a standard harrow break, stir, and level soil in a single pass.

20 Teeth Per Foot.
Close tooth spacing delivers thorough coverage and even residue handling.

High-Carbon Diamond Teeth.
Replaceable diamond-shaped teeth hold their edge for consistent performance.

Built to Flex and Last

One-Piece Main Frame.
A heavy-duty frame of rectangular tubular steel stands up to heavy use.

Fully Flexible Design.
The frame flexes to handle heavy residue and uneven ground without gaps.

Two Pitch Settings.
Run teeth at a 70-degree standard angle or a 49-degree reverse angle to match conditions.

Versatile Field Performance

Long Hitch.
An extended hitch keeps turns easy behind a tractor or another implement.

Ridge Leveling.
Smooths ridges left behind by fall tillage ahead of planting.

Straw Management.
Manages small grain straw for a cleaner, more even field surface.

Broadcast Seeding.
Works soil to a depth suited for covering broadcast seed.
