VT1110 Turbo-Max®

Great Plains VT1110 Turbo-Max®

Description

The Great Plains VT1110 Turbo-Max delivers true vertical tillage in a narrow-transport package. Built in 20′ and 25′ working widths, it folds to under 12′ for easy travel between fields. Hydraulic gangs adjust from 0 to 6 degrees, so you can dial in tillage intensity from the cab.

Compare Models

Two models to choose from. Click any model below to see full specs.

VT1110-20 | 20′ Width | 180+ HP

Model	VT1110-20
Condition	New
Type	Folding Vertical Tillage Cultivator
Coulter Spacing	7.5″
Number of Coulters	65
Engine HP Requirement (PTO)	180+
Tillage Width	20′
Transport Width	11’8″
Transport Height	11’2″
Operating Depth	1″-5″
Weight (Approx.)	20,700 Lbs.

VT1110-25 | 25′ Width | 230+ HP

Model	VT1110-25
Condition	New
Type	Folding Vertical Tillage Cultivator
Coulter Spacing	7.5″
Number of Coulters	81
Engine HP Requirement (PTO)	230+
Tillage Width	25′
Transport Width	11’8″
Transport Height	13′
Operating Depth	1″-5″
Weight (Approx.)	25,000 Lbs.

Condition

New

Features

Vertical Tillage & Blades

True Vertical Cutting
Turbo blades spaced 7.5 inches apart cut vertically without the shearing of concave blades.

Turbo Blade Sizing
Standard 20-inch blades handle medium to heavy soils and resist breakage in rocky ground.

Hydraulically-Adjustable Gang Angle
Hydraulic cylinders angle the gangs from 0 to 6 degrees without leaving the cab.

Finishing & Residue Management

Basket Options
Choose single or double baskets with flat or round bars for your soil.

Rolling Spike Harrows or Chopper Reels
Pick spike harrows to level seedbeds or chopper reels for tough residue.

Torsion Mount
Standard torsion mounts deliver a smooth, uniform finish behind the tillage tool.

Transport & Control

Narrow Transport Folding
The folding frame narrows to under 12 feet for easy road travel.

Implement Command (Optional)
The optional Implement Command system adjusts finishing reel depth and pressure from the cab.
