Great Plains Vt1100 Turbo-Max®

Call Now Get A Quote Schedule A Visit Value Your Trade Apply for Financing

Description

The Great Plains VT1100 Turbo-Max scales vertical tillage up to working widths of 40 feet. Choose single or double baskets, standard or 22-inch blades, and spike harrows or chopper reels to match your ground. Hydraulic gangs angle from 0 to 6 degrees, giving you cross-season control from the cab.

Compare Models

Five models to choose from. Click any model below to see full specs.

VT1100-20 | 20′ Width | 180+ HP
Model VT1100-20
Condition New
Type Folding Vertical Tillage Cultivator
Coulter Spacing 3¾” Effective (7½” Per Gang)
Number of Coulters 65
Engine HP Requirement (PTO) 180+
Tillage Width 20′
Transport Width 15’7″
Transport Height 9’4″
Weight (Approx. Max w/ Attachments) 17,800 Lbs.
VT1100-25 | 25′ Width | 230+ HP
Model VT1100-25
Condition New
Type Folding Vertical Tillage Cultivator
Coulter Spacing 3¾” Effective (7½” Per Gang)
Number of Coulters 81
Engine HP Requirement (PTO) 230+
Tillage Width 25′
Transport Width 15’7″
Transport Height 12’4″
Weight (Approx. Max w/ Attachments) 22,250 Lbs.
VT1100-30 | 30′ Width | 285+ HP
Model VT1100-30
Condition New
Type Folding Vertical Tillage Cultivator
Coulter Spacing 3¾” Effective (7½” Per Gang)
Number of Coulters 97
Engine HP Requirement (PTO) 285+
Tillage Width 30′
Transport Width 15’7″
Transport Height 14’4″
Weight (Approx. Max w/ Attachments) 26,375 Lbs.
VT1100-35 | 35′ Width | 345+ HP
Model VT1100-35
Condition New
Type Folding Vertical Tillage Cultivator
Coulter Spacing 3¾” Effective (7½” Per Gang)
Number of Coulters 113
Engine HP Requirement (PTO) 345+
Tillage Width 35′
Transport Width 17′
Transport Height 14’7″
Weight (Approx. Max w/ Attachments) 29,000 Lbs.
VT1100-40 | 40′ Width | 380+ HP
Model VT1100-40
Condition New
Type Folding Vertical Tillage Cultivator
Coulter Spacing 3¾” Effective (7½” Per Gang)
Number of Coulters 129
Engine HP Requirement (PTO) 380+
Tillage Width 40′
Transport Width 17’7″
Transport Height 14’4″
Weight (Approx. Max w/ Attachments) 36,905 Lbs.
Condition New

Features

Vertical Tillage & Blades

True Vertical Tillage Machine
Turbo blades spaced 7.5 inches apart cut vertically without shearing caused by concave blades.

Choice of Turbo Blades
Choose standard 20-inch blades for heavier soils or optional 22-inch blades for lighter ground.

Hydraulically-Adjustable Gang Angle
Hydraulic cylinders angle the gangs from 0 to 6 degrees without leaving the cab.

New Frame Design
The redesigned frame supports new attachments and heavier transport axles and tires.

Finishing & Residue Management

Optional Single or Double Baskets
Choose single or double baskets with flat or round bars for your soil.

Rolling Spike Harrows or Chopper Reels
Pick spike harrows to level seedbeds or chopper reels for tough residue.

Torsion Mount
Standard torsion mounts deliver a smooth, uniform finish behind the tillage tool.

Turbo-Seeder Plus (Optional)
The optional Turbo-Seeder Plus tills soil and plants cover crops in one pass.

Technology & Durability

Implement Command (Optional)
The optional Implement Command system adjusts and monitors the implement from an ISOBUS monitor.

Virtually Maintenance-Free Bearings
Lip seals and coated bushings keep gang bearings sealed and free of grease maintenance.
