Kuhn SR Series SpeedRake Wheel Rakes

Description

From small-acreage producers to large custom operators, the KUHN SR Series SpeedRake wheel rakes cover every job. The lineup spans the SR 100 GII, SR 300, SR 600 GII, and SR 800 Series. Each one uses a ground-driven design, so it works with lower horsepower tractors and saves fuel. First, spring-suspended arms and adjustable ground pressure keep raking clean across changing field conditions. Then a hydraulic rake lift and independent windrow width control let you fine-tune each pass from the seat.

Every SR Series rake is built to match your operation. You can choose from 8 to 19 rake wheels and working widths from about 19 to nearly 30 feet. Tapered roller bearings and heavy-duty components also keep these rakes running through demanding hay seasons. Finally, narrow transport widths and optional tandem axles make road moves safe and simple.

At Parallel Ag, we know hay and forage equipment inside and out. Contact us today to find the KUHN SR Series wheel rake that fits your fields.

Compare Models

SR 100 GII Series

18’10” SR 108 GII | 8 Wheels / 20 HP.

Model	SR 108 GII.
Working Width	18 ft. 10 in.
Rake Wheels	8.
Minimum PTO Power	20 HP.

21’2″ SR 110 GII | 10 Wheels / 20 HP.

Model	SR 110 GII.
Working Width	21 ft. 2 in.
Rake Wheels	10.
Minimum PTO Power	20 HP.

23’4″ SR 112 GII | 12 Wheels / 30 HP.

Model	SR 112 GII.
Working Width	23 ft. 4 in.
Rake Wheels	12.
Minimum PTO Power	30 HP.

SR 300 Series

20’10” SR 310 | 10 Wheels / 20 HP.

Model	SR 310.
Working Width	20 ft. 10 in.
Rake Wheels	10.
Minimum PTO Power	20 HP.

24’2″ SR 312 | 12 Wheels / 30 HP.

Model	SR 312.
Working Width	24 ft. 2 in.
Rake Wheels	12.
Minimum PTO Power	30 HP.

28 ft. SR 314 | 14 Wheels / 35 HP.

Model	SR 314.
Working Width	28 ft.
Rake Wheels	14.
Minimum PTO Power	35 HP.

SR 600 GII Series

25 ft. SR 612 GII | 12 Wheels / 30 HP.

Model	SR 612 GII.
Working Width	25 ft.
Rake Wheels	12.
Minimum PTO Power	30 HP.

28 ft. SR 614 GII | 14 Wheels / 35 HP.

Model	SR 614 GII.
Working Width	28 ft.
Rake Wheels	14.
Minimum PTO Power	35 HP.

31 ft. SR 616 GII | 16 Wheels / 40 HP.

Model	SR 616 GII.
Working Width	31 ft.
Rake Wheels	16.
Minimum PTO Power	40 HP.

SR 800 Series

27 ft. SR 800 17-Wheel | 17 Wheels / 80 HP.

Model	SR 800 17-Wheel.
Working Width	27 ft.
Rake Wheels	17.
Minimum PTO Power	80 HP.

29’6″ SR 800 19-Wheel | 19 Wheels / 80 HP.

Model	SR 800 19-Wheel.
Working Width	29 ft. 6 in.
Rake Wheels	19.
Minimum PTO Power	80 HP.

Condition	Used
Model	SR Series SpeedRake®

Features

Rugged, Reliable Design

Ground-Driven Operation.
This low horsepower design works with smaller tractors to save fuel and cost.

Heavy-Duty Components.
Tapered roller bearings and high-strength materials hold up to years of raking.

Fast, Easy Adjustment

Hydraulic Rake Lift.
Raise and lower rake wheels from the cab for quick end-of-row transitions.

Independent Windrow Width Control.
Adjust windrow width without changing raking width to match your baler or chopper.

Tool-Free Setup.
Spring-suspended arms and simple adjustment points make setup fast in the field.

Clean Raking, Easy Transport

Adjustable Ground Pressure.
Optimized wheel suspension delivers cleaner windrows and less ash content.

Narrow Transport Profile.
Fold down quickly for safe, compact road moves between fields.

Expansion & Accessory Kits.
Add windguards, kicker wheels, or hitch extensions to match your operation.
