Rhino REB60 Tiller

Call Now Get A Quote Schedule A Visit Value Your Trade Apply for Financing

Description

The Rhino REB60 tiller tackles landscaping, orchard cleanup, and general soil conditioning with ease. It tills a 59-inch width and reaches a maximum depth of 7-1/2 inches. Because six hardened L-shaped blades sit on every rotor flange, the machine breaks up tough ground reliably. In addition, the gearbox housing is cast for extra strength, and hitch points are continuously welded to the mainframe. That combination keeps the Rhino REB60 tiller ready for repeated heavy use with fewer repairs.

A CAT 4 driveline with slip-clutch protection guards the drivetrain from shock loads and overload damage. Meanwhile, 1/2-inch steel end plates add extra durability at the points that wear fastest. The Rhino REB60 tiller also belongs to a family spanning 60, 72, and 84-inch widths. As a result, buyers can size a Rebel Series tiller to match their tractor and acreage.

Compare Models

Three sizes to choose from. Click any model below to see full specs.

REB60 | 59 in Tilling Width | 25–45 HP
Model Rhino REB60
Tilling Width 59 in
Overall Width 66 in
Tilling Depth (Max.) 7-1/2 in
Hitch – Standard CAT 1
Hitch – Quick Hitch CAT 1 QH
Knife Type “L”
Number of Knives 42
Number of Flanges 7
Recommended PTO HP (Min/Max) 25 / 45 HP
Rotor Speed 211 RPM
Driveline Size CAT 4
Driveline Protection Slip Clutch
Gearbox Housing Cast
End Plate Thickness 1/2 in
Rotor/Blade Rotation Dia. 17 in
Rotor Shaft Dia. 3 in
Rotor Drive Type Gear Driven
Tine Rotation Standard
Approx. Weight 673 lbs
REB72 | 70.5 in Tilling Width | 35–55 HP
Model Rhino REB72
Tilling Width 70.5 in
Overall Width 78 in
Tilling Depth (Max.) 7-1/2 in
Hitch – Standard CAT 1
Hitch – Quick Hitch CAT 1 QH
Knife Type “L”
Number of Knives 54
Number of Flanges 9
Recommended PTO HP (Min/Max) 35 / 55 HP
Rotor Speed 211 RPM
Driveline Size CAT 4
Driveline Protection Slip Clutch
Gearbox Housing Cast
End Plate Thickness 1/2 in
Rotor/Blade Rotation Dia. 17 in
Rotor Shaft Dia. 3 in
Rotor Drive Type Gear Driven
Tine Rotation Standard
Approx. Weight 747 lbs
REB84 | 82.5 in Tilling Width | 45–65 HP
Model Rhino REB84
Tilling Width 82.5 in
Overall Width 90 in
Tilling Depth (Max.) 7-1/2 in
Hitch – Standard CAT 1 & 2
Hitch – Quick Hitch CAT 1 & 2 QH
Knife Type “L”
Number of Knives 66
Number of Flanges 11
Recommended PTO HP (Min/Max) 45 / 65 HP
Rotor Speed 211 RPM
Driveline Size CAT 4
Driveline Protection Slip Clutch
Gearbox Housing Cast
End Plate Thickness 1/2 in
Rotor/Blade Rotation Dia. 17 in
Rotor Shaft Dia. 3 in
Rotor Drive Type Gear Driven
Tine Rotation Standard
Approx. Weight 817 lbs
Condition New
Model REB60

Features

Blades & Tilling

Six Hardened “L” Blades per Rotor Flange
Hardened L-shaped blades deliver reliable soil breakup and long wear life.

Gear-Driven Rotor
A gear-driven rotor system provides consistent power transfer for dependable tilling performance.

Frame & Durability

Cast Iron Gearbox Housing
A cast iron housing stands up to the stress of heavy-duty tilling work.

Continuously Welded Hitch Points
Front-to-rear hitch points are welded continuously to the mainframe for added strength and fewer failure points.

1/2-Inch Steel End Plates
Heavy steel end plates add extra durability where wear is greatest.

Driveline & Hitch

Slip Clutch Driveline Protection
Standard slip clutch protection helps guard the driveline from shock loads and overload damage.

CAT 1 or CAT 1 & 2 Quick-Hitch Compatible
Standard and Quick Hitch options make attaching and detaching the tiller fast and simple.
