MI 20 G

Description

The MI 20 G industrial front loader runs on gas with a maximum load capacity of 2 tonnes, and is suited to intensive use both indoors and outdoors. The innovative design will win its fair share of fans and it’s easy to get up and running with the ergonomic controls.

Accessibility is no problem with a large handle grip, anti-slip footstep and doors on both sides, whilst the driver’s position has been designed with comfort in mind so long shifts are less exhausting. The cab is fully enclosed with an adjustable steering column, and visibility when performing maneuvers has been optimized with the specially designed counterweight.

ConditionNew
Lifting height10'10"
Lifting capacity4400 lb
Drawbar pull
Moving speed11.7 mph
Mast inclination (front/rear)
Length (up to the back of the fork)8'1"
Total length (fork included)11'10"
Wheelbase length5'3"
Width3'9"
Fork carriage width3'5"
Aisle width (with a 1000 x 1200 palette)12.68
Aisle width (with a 800 x 1200 palette)13.33
Height7'2"
Weight (unladen)7964 lb
Front axle weight (laden)10846 lb
Front axle weight (unladen)3784 lb
Rear axle weight (laden)1518 lb
Rear axle weight (unladen)4180 lb
Turning radius7'3"
Ground clearance0'7"
EnergyGas
Engine brandNissan
Engine type3B
Power38 KW
Number of cylinders2400
Total capacity2488 cm3
Transmission typeTorque converter
Pressure160 bars
Standard tyresSuper-elastic
Number of wheels (front/rear)2/2
Number of drive wheels (front/rear)2/0
Number of steering wheels (front/rear)0/2
Standard mast typeDuplex
Free lift (standard mast, lowered)0'6"
Standard mast height (when raised)14'3"
Driving position noise levels80 dB
