Kioti KL5521 loader pkg with 72″ bucket

Description

Fits all DK10SE Series Cab Models. (DK4210SE HC, DK4710SE HC, DK5310 HC, DK6010SE HC) The KIOTI KL5521 front end loader is specifically designed for the Cab models of the DK10SE Series. The KIOTI loader, with a built-in parking stand, is designed to be quickly and easily attached and detached. KL Series loaders utilize the tractor’s hydraulic system, feature single-lever control with float and come with a bucket level indicator. *Specifications may vary with tractor model, front axle configurations, tire size option and type of attachment and are subject to change without notification.

Standard Features

  • Contoured design complements tractor styling.
  • Low profile design maximizes operator’s visibility.
  • Designed to be quickly and easily attached and detached.
  • A built-in parking stand on the front end loader provides quick and easy connection.
  • Mid-mount style frame for engine accessibility.
  • A bucket level indicator is standard.
  • Color complements KIOTI tractor.
ConditionNew
ModelKL5521
Maximum Lift Height to Pivot Pin107.7 in. (2,735 mm)
Clearance w/ Bucket Level96.3 in. (2,446 mm)
Clearance w/ Bucket Dumped78.8 in. (2,001 mm)
Reach at Maximum Height (45º)22.7 in. (576 mm)
Maximum Dump Angle46º
Reach w/ Bucket on Ground71.1 in. (1806 mm)
Maximum Rollback Angle41º
Digging Depth Below Grade8.6 in. (218 mm)
Overall Height in Carry Position54 in. (1371 mm)
Bucket Depth (Inner Shell)18.5 in. (470 mm)
Bucket Height22 in. (560 mm)
Bucket Length (Pivot Pin)26 in. (660 mm)
Lift Capacity to Full Height at Pivot Pins2,474 lbs. (1,122 kg)
Breakout Force at Pivot Pins3,895 lbs. (1,767 kg)
Bucket Rollback Force at Ground Line3,148 lbs. (1,428 kg)
Relief Valve Setting (Loader Control Valve)2,774 psi (195 kg/cm²)
Rated Flow (Tractor System)9.62 gpm (36.4 L/min)
Bucket Size(s) Available66" QA / 72" QA
Bucket Capacity (Heaped)66 in.: 14.5 cu. ft. / 72 in.: 16.0 cu. ft.
Approximate Weight (With Bucket)66 in.: 1,361 lbs. (617 kg) / 72 in.: 1,389 lbs. (630 kg)
