BH75

Description

  • Curved boom offers better visibility and reaches over obstacles with little repositioning
  • High digging forces powers through hard, rocky, root-fill ground
  • Optional mechanical thumb available
  • Sub-frame or 3-point hitch mounts are compatible with most loaders and undermount mowers
  • Ultimate operator comfort with high-back seat and walk-through platform
  • High capacity buckets move more material in less time
  • Bolt-on bucket teeth are durable and easy to replace
ConditionNew
ModelBH75
Tractor PTO HP20-40
Maximum Digging Depth90 (7.5 ft)
ThumbOptional mechanical
Digging Depth - 8 ft Flat Bottom (in)70
Reach from Swing Pivot (in)119
Loading Height (in)73
Loading Reach (in)46
Transport Height (in)74
Transport Length (in)45
Approx. Weight - Frame Only (lbs)842
Swing Arc (degrees)180
Bucket Rotation (degrees)180
Stabilizer Spread - Up (transporting) (in)52
Stabilizer Spread - Down (operating) (in)83
Relief Pressure (psi)2,465
Bucket Digging Force (lbs)3,380
Dipperstick Digging Force (lbs)2,230
Trenching Bucket Widths (in)9, 12, 16, 18, 24
Flip-Over Stabilizer PadsStandard
Stabilizer Street PadsOptional
PTO Pump KitOptional
2-Cylinder SwingYes
Warranty2 year limited, including the tractor

Features

  • 7½-foot maximum digging depth
  • Tractor PTO HP range: 20-40
  • Bucket options: 9”, 12”, 16”, 18”, 24”
  • Swing cushioning provides smooth, superior control – even at the ends of the swing arc
  • Bolt-on bucket teeth are durable and easy to replace
  • Greasable end pins are simple to maintain and extend work life
  • High ramp angle and ground clearance make transporting easy
  • Sub-frame or 3-point hitch mounts are compatible with most loaders and undermount mowers
  • Available in black or paint colors to match most tractor brands
  • Optional mechanical thumb adds versatility to any job
