AS1250 & AS1250XP

Description

APACHE SPRAYERS | AS1250 AND AS1250XP

Ideal for the large acreage farmer, the AS1250 features a Cummins Tier 4F 260 hp engine and boasts a 1200 gallon tank in standard poly or upgrade to the all-new stainless steel tank option. The Apache AS1250 Sprayer is the highest-capacity model in the lineup, yet it still weighs far less than the competition. And its mechanical drive makes it simple to operate and maintain, while nimble enough to work in field conditions competitive sprayers can’t. Spray more ground faster with reduced soil compaction and less maintenance. Additionally, you’ll get the same superior fuel economy and state-of-the-art precision options you would in any of the other Apache Sprayer models.

Ready to go big or go home? Upgrade from the standard plastic-poly tank to our all-new stainless steel tank, an exclusive option for the AS1250 and AS1250XP Sprayers.

Find out why the Apache Sprayer AS1250 is the ideal large acreage sprayer.

ConditionNew
ModelAS1250 & AS1250XP
TANK CAPACITY Standard Poly Tank or NEW Stainless Steel Upgrade1,200 gal
WEIGHT (APPROXIMATE DRY WEIGHT)22,500 lbs
AXLE WIDTH120″ fixed or 120″-160″ hydraulic adjustable
TRANSPORT WIDTH & HEIGHT144″ maximum
OVERALL LENGTH290″ minimum
TURNING RADIUS20′
WHEEL BASE15′
FRONT TIRES (STANDARD)Michelin 380/80R38
REAR TIRES (STANDARD)Michelin 380/90R46
CROP CLEARANCE50″
BOOMS90′, 60/90′, 100′ steel or Pommier 100′, 120′, or 132′ aluminum
RINSE TANK100 gal
RATED HORSEPOWER260HP or 300HP optional
DRIVELINE EFFICIENCY90%
PTG: HP PER 1,000 lbs.11 (12.7 with 300HP)
FUEL TANK CAPACITY90 gal
TRANSMISSIONZF power shift 6 speed
ENGINE
Cummins Performance Series V

Features

AS1250 Product Enhancements

STAINLESS STEEL TANK
Exclusively for the AS1250 and AS1250XP, our stainless steel tank has been redesigned, including the baffle, tank agitation, tank rinse, sump, sight gauge, and tank mounts for better performance.

FRONT ENTRY TO CAB
New front entry, same legendary Apache view. Our engineering team preserved the visibility of the front axle, angling the grates, and performed test after test to ensure the view was not compromised.

OPERATION CONVENIENCE
To improve productivity and convenience, operators can now perform rinse, agitate, and other fill-station functions right from the cab (with the 3″ fill option). We’ve also simplified our fuel and hydraulic tanks for ease of fill.

FRONT AXLE
More durable than ever. All AS Series Sprayers feature an improved front axle, making for uniform steering and better suspension with new struts boasting 8x better performance.

IR LED BACKUP CAMERA
The Voyager VCMS20B high-resolution color IR LED camera boasts a 145 degree wide viewing angle that provides coverage and an improved depth of field.

AS1250 & 1250XP Options

Our sprayers are reliable for many reasons, one being our lean manufacturing to build sprayers exactly the way you want them. That means we don’t force you to pay for the things you don’t want or need. Our “a la carte” menu gives you the freedom to choose upgrades, so your sprayer is customized for you and your operational needs.

OptionDescription
Extra Power with XPThe XP package from Apache Sprayers provides the perfect
combination of power, traction and efficiency, along with the simplicity of a mechanical drive transmission.
Stainless SteelThe all-new 1200-gallon stainless steel product tank features a redesigned baffle, tank agitation, tank rinse, sump, sight gauge, and tank mounts.
Fence-Row NozzlesThese added nozzles are great for keeping fence lines and
outer edges of fields clean. The extra nozzle can be added to the left or right side of the boom, or both.
3-Inch Product FillFill up faster thanks to the upgraded 3-inch diameter
product fill connection.
Hypro® Cleanload™The Hypro Cleanload is a self contained eductor system that allows operators to mix liquid and dry chemicals safely and quickly.
FendersIf you want mud splash-back protection, fenders are a great option to help keep things clean and prevent dust and mud clogs. Available in the front, rear, or a combination of each.
Enhanced Lighting PackageOur optional LED lighting package produces more light, while consuming less energy. This lighting package features 64 LED bulbs, located above the grille and cab and next to the fill station. The lights are situated to reduce bounceback reflection. LED bulbs have an average lifespan of tens of thousands of hours.
Power MirrorsOperators have the option of adjusting the single power side mirror attached to the cab from within the cab.
