Compare Models
Three models to choose from. Click any model below to see full specs.
MF 5S.115 | 115 HP | Dyna-6 or Dyna-VT
| Model | MF 5S.115 |
| Max Power (HP) | 115 |
| Engine | AGCO Power 4.4L, 4-cylinder |
| Transmission | Dyna-6, Dyna-VT |
| Max Torque (ft/lb) | 460 |
| Lift Capacity (lb) | 10,300 |
MF 5S.135 | 135 HP | Dyna-6 or Dyna-VT
| Model | MF 5S.135 |
| Max Power (HP) | 135 |
| Engine | AGCO Power 4.4L, 4-cylinder |
| Transmission | Dyna-6, Dyna-VT |
| Max Torque (ft/lb) | 540 |
| Lift Capacity (lb) | 10,300 |
MF 5S.145 | 145 HP | Top of the Line
| Model | MF 5S.145 |
| Max Power (HP) | 145 |
| Engine | AGCO Power 4.4L, 4-cylinder |
| Transmission | Dyna-6, Dyna-VT |
| Max Torque (ft/lb) | 550 |
| Lift Capacity (lb) | 10,300 |
*Max power @ 2,000 RPM. Max torque @ 1,600 RPM. All models available with Essential or Efficient specification packages.
Features
The all-rounder for dairy, hay, and livestock operations.
The Massey Ferguson 5S Series is the perfect blend of power, agility, and value. With the highest power-to-weight ratio in its class, a 13-foot turning radius, and best-in-class visibility, the 5S handles loader work, mowing, feeding, and baling with ease. The AGCO Power 4.4L 4-cylinder engine pairs with your choice of Dyna-6 (24×24) or Dyna-VT transmission, both with Super Eco mode that hits 25 mph at just 1,530 RPM for serious fuel savings. With up to 10,300 lbs of rear lift capacity, 6,600 lbs of front linkage capacity, and a 600-hour engine service interval, the 5S delivers the productivity, efficiency, and dependability Massey Ferguson is known for.
Power
AGCO Power 4.4L 4-Cylinder Engine
Tier 4 Final compliant, delivering maximum power from 115 HP to 145 HP. Compact All-in-One (DOC+SCR+SC) aftertreatment system delivers more power with reduced fuel and DEF consumption.
Dyna-6 Transmission
Renowned for outstanding, robust reliability with smooth and effortless operation. 24×24 semi-powershift with six Dynashift ratios stepped in four ranges. AutoDrive takes care of upshifts and downshifts automatically.
Dyna-VT Transmission
Continuously variable transmission (CVT) enables stepless power and smooth operation under the toughest conditions. Choose your exact speed without compromising engine RPM.
Super Eco Operation
Standard Super Eco ensures top speed is achieved at very low engine RPM, cutting fuel consumption. Hits 25 mph at just 1,550 RPM.
600-Hour Engine Service Interval
Long service intervals cut the cost of ownership and reduce downtime.
Hydraulic Performance
High-Capacity Rear Linkage
Rear linkage lifts up to 10,300 lbs. Fully adjustable lift rods and heavy-duty stabilizers provide plenty of adjustment for the perfect attachment.
Closed-Center 29 GPM Pump
Variable displacement swash plate pump with load-sensing control delivers high flow rates at low engine speeds, maintaining high output with economy.
Integrated Front Linkage System
6,600 lb lift capacity (+17% vs previous range) at the ball ends. Stronger, more compact design enables you to take full advantage of the 5S Series power. Matches the optional front suspension.
Auxiliary Spool Valves
Up to four spool valves to meet your needs. Essential Models offer mechanical control with optional dedicated joystick. Efficient Models get an armrest-mounted electronic joystick.
High-Efficiency PTO
Choice of three speeds selected easily using rocker switches. Electro-hydraulic engagement with three-position safety switch (On, Off, Lock/Brake). External fender-mounted switches also available.
Maneuverability
13-Foot Turning Radius
Industry-leading turning radius — one of the best on the market. Specially designed cutaways in the chassis and hood help deliver tight turns for easy access to confined areas and buildings.
Stronger Suspended Front Axle
New, stronger suspended front axle works with the 3-ton capacity front linkage to improve efficiency and enable larger front-mounted implements.
Hydraulic Cab Suspension
Electronically controlled hydraulic suspension uses two longer-stroke cylinders (nearly 4 inches) and three accumulators to absorb shocks.
SpeedSteer
Optional SpeedSteer allows sharp turns with far fewer rotations of the steering wheel, making headland and turnrow turns quicker and easier.
Hydralock
Delivers true four-wheel drive with fast, fully simultaneous engagement of the front and rear differential locks.
Comfort & Operator Environment
Best-in-Class Visibility
Visibility down to just 13 feet ahead of the tractor over the slim dashboard and narrow steep-nose hood. Perfect for loader operations. Optional Visio Roof adds even more visibility when working with loaders.
Quiet, Comfortable Cab
Easy-to-access cab with large doors and wide, well-spaced steps. 360-degree visibility, 64.4 sq ft of glass, and cab suspension for a smooth, productive workday.
Multipad Lever
Standard on Efficient Models. The Multipad lever operates the transmission, cruise control, rear linkage, PTO, headland management, and spool valves through the integrated mini-joystick.
Power Control Lever
Left-hand Power Control lever provides three-in-one operation. Shuttle forward/reverse, shift Dynashift speeds and ranges, and select neutral, leaving the right hand free for loader operations.
Essential or Efficient Packages
Essential is the base specification with T-handle transmission lever, AutoDrive Dyna-6, Brake-to-Neutral, and MF Connect. Efficient adds cab suspension, MultiPad armrest, Datatronic 5 terminal, and ISOBUS-compatible precision farming package.
Farm Management Technology
Datatronic 5 Touchscreen Terminal
Standard on Efficient Models. The 9-inch touchscreen puts all functions of the 5S Series at the operator’s fingertips. Manages tractor functions, ISOBUS, MF Guide, MF Section Control, and MF Rate Control.
MF Guide
Full-featured, hands-free steering system with sub-meter, decimeter, and centimeter accuracy. Choice of NovAtel or Trimble receivers and correction signals.
MF Section Control & Rate Control
Section Control minimizes overlaps by 12% by controlling sections automatically. Rate Control adjusts application rate on the move, saving precious inputs.
MF Connect Telemetry
Coordinate, optimize, and seamlessly connect your fleet. Remotely access machine data in real time to monitor and analyze operating information.
MF TaskDoc & TaskDoc Pro
Create and securely transfer detailed job records between the field and office. Puts precision-measured data at your fingertips.
