Kinze 1721 Dual-Auger Grain Cart

Call Now Get A Quote Schedule A Visit Value Your Trade Apply for Financing

Description

The Kinze 1721 dual auger grain cart handles up to 1,700 bushels for high-volume harvest days. A clean corner auger design gives operators a clear line of sight to the combine. Unload speeds reach 750 bushels per minute through the 24-inch vertical auger. Dedicated 36-inch by 108-inch tracks spread weight for a low-pressure footprint. One joystick controls auger tilt, spout tip, horizontal auger, and flow gate. Horizontal auger cleanout doors make crop changeovers fast between fields. A torque-limiting driveline clutch protects components with automatic reset. This cart carries the only 2-year warranty in the grain cart industry.

Condition New
Model 1721 Dual-Auger Grain Cart

Specifications

Model 1721 Dual Auger Grain Cart.
Condition New.
Type Corner Dual Auger Grain Cart.
Heaped Capacity 1,700 Bu.
Unload Speed (Maximum) 750 Bu./Min.
Undercarriage Tracks (36" x 108" Standard / 36" x 100" Optional).
Ground Contact Pressure 17 PSI.
Vertical Auger 22" Diameter Flighting, 24" Diameter Tube.
Horizontal Auger 20" Diameter Flighting, 22" Diameter Tube.
Gearbox Bevel & Spur Gears (2:1 Ratio).
Drive Belts Two 4-Band Multi-Strand V-Belts.
PTO 1-3/4" Diameter, 20 Spline, 1000 RPM.
Scale Package 5-Point (Standard).
Tarp Manual (Standard) or Electric (Optional).
Tractor Horsepower (Minimum) 450 HP.
Tractor Hydraulics (Minimum) 2 SCVs; 2,320 System PSI.
Overall Width 13'0".
Overall Length 39'3".
Overall Height 12'5".
Weight (Empty) 35,180 Lbs.
Hitch Weight (Empty) 5,250 Lbs.
Hitch Weight (Loaded) 7,380 Lbs.
Warranty 2-Year (Industry Exclusive).

Features

Auger & Unloading

Clean Corner Dual Auger Design.
This layout gives you a clear line of sight to the combine spout.

Joystick Auger Control.
One joystick handles auger tilt, spout tip, horizontal auger, and flow gate.

Aligned Tip Spout.
A refined spout delivers smoother flow and more precise unloading.

Horizontal Auger Cleanout Doors.
Cleanout doors speed up crop changeovers between fields.

Undercarriage & Mobility

High-Flotation Tracks.
Standard 36 by 108 inch tracks spread weight for a lighter footprint.

Low-Profile Short Side Design.
A shorter profile handles rolling terrain with ease.

Thickened Edge Auger Design.
Thicker auger edges extend wear life by 50 percent.

Technology & Serviceability

Scale-Tec POINT Scale Indicator.
This indicator pairs Bluetooth connectivity with ISOBUS compatibility for accurate readouts.

Remote Scale Readout.
An optional readout lets the combine operator monitor weight in real time.

Central Grease Bank.
One grease bank lubricates every point from ground level.

Vented Grain Tank.
A vented tank improves airflow during loading and unloading.

Tool-Less Inspection Cover Access.
Open the inspection cover and cleanout without reaching for tools.

Hydraulic Hose Cradle.
Color-coded hose ends and a cradle simplify tractor hookup.
