1614

Description

  • Spring Assist Pole
  • Adjustable Wheel Base
  • Greasable Automotive Style Ball Joints
  • Retractable Automatic Relock Tongue Latch
  • Tapered Roller Bearings in Main Pivot Points
  • Safety Chain
  • Full Contact Turn Stops distributes the pressure exerted in tight dragging turns along the bolster face – this reduces the possibility of bunk damage or collapse.
  • 1622 Running Gear has a 4-bolt brake flanges as standard equipment so that optional hydraulic disc brakes may be installed.
ConditionNew
Model1614
1614
CAPACITY28,000 LBS
APPROX. WEIGHT1,155 LBS.
SPINDLES2-1/4” Dia. C1045 Cold Rolled
HUBS8 BOLT
BOLSTER STAKES42.5” Fixed
WHEEL BASEADJUSTABLE
REAR AXLE7 x 3 x .313 Wall
FRONT AXLE7 x 3 x .250 Wall
WARRANTY: SEE OPERATORS MANUAL FOR WARRANTY DETAILS AND LIMITATIONS. H&S RESERVES THE RIGHT TO CHANGE ITS PRODUCTS OR THE DESCRIPTION AT ANY TIME WITHOUT NOTICE OR OBLIGATION. MODELS AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE.

Features

  • Spring Assist Pole
  • Adjustable Wheel Base
  • Greasable Automotive Style Ball Joints
  • Retractable Automatic Relock Tongue Latch
  • Tapered Roller Bearings in Main Pivot Points
  • Safety Chain
  • Full Contact Turn Stops distributes the pressure exerted in tight dragging turns along the bolster face – this reduces the possibility of bunk damage or collapse.
  • 1622 Running Gear has a 4-bolt brake flanges as standard equipment so that optional hydraulic disc brakes may be installed.
